The fix

// Rotation by angle a about unit axis k: R = cos(a) I + sin(a) [k]x + (1 - cos(a)) k k^T
static mat3_t rodrigues(const vec3_t k, const float32_t a)
{
    assert_param(fabsf(vec3_dot(k, k) - 1.0f) < 1e-3f);  // axis must be a unit vector
    assert_param(isfinite(a));

    const float32_t c = cosf(a), s = sinf(a), t = 1.0f - c;
    return (mat3_t){ .m = {
        { c + t * k.x * k.x,       t * k.x * k.y - s * k.z, t * k.x * k.z + s * k.y },
        { t * k.y * k.x + s * k.z, c + t * k.y * k.y,       t * k.y * k.z - s * k.x },
        { t * k.z * k.x - s * k.y, t * k.z * k.y + s * k.x, c + t * k.z * k.z       },
    } };
}

// Road gradient (rad) from an accelerometer sample (g) and wheel acceleration (m/s^2)
float32_t roadGradient(const vec3_t accel, const float32_t wheelAccel)
{
    // A NaN would poison every filter downstream; out-of-range values are clamped below
    assert_param(isfinite(accel.x) && isfinite(accel.y) && isfinite(accel.z));
    assert_param(isfinite(wheelAccel));
    assert_param(fabsf(Mount.pitch) < (float32_t) M_PI_4);  // calibration sanity

    // The IMU is mounted pitched, so the bike's forward and up axes are not the sensor's
    const float32_t cp = cosf(Mount.pitch), sp = sinf(Mount.pitch);
    const vec3_t fwd = {  cp, sp, 0.0f };
    const vec3_t up  = { -sp, cp, 0.0f };

    // Leaning in a corner reads as slope: measure the lean, roll gravity back upright
    const float32_t lean = atan2f(accel.z, vec3_dot(accel, up));
    const vec3_t    g    = mat3_mul_vec3(rodrigues(fwd, -lean), accel);

    // Remove the bike's own acceleration and clamp what no road can produce
    const float32_t along = constrainf32(vec3_dot(g, fwd) - wheelAccel / G_MPS2, -3.0f, 3.0f);
    const float32_t above = constrainf32(vec3_dot(g, up), 0.0f, 2.0f);

    return atan2f(along, above);
}
